MPN

Texas Instruments PTH08080WAH, DC-DC Power Supply Module 2.25A 4.5 V Input, 300 kHz 5-Pin, DIP Module


5 Within 2 working day(s) (EU stock)
64 Within 2 working day(s) (EU stock)
Add to Basket

Price Each

€6.58

(exc. VAT)

€7.96

(inc. VAT)

units

Added

Packaging Options:
RS Stock No.:
661-7948
Mfr. Part No.:
PTH08080WAH
Manufacturer:
Texas Instruments
unitsPer unit
1 - 2€6.58
3 - 5€6.40
6 - 11€6.24
12 - 23€6.08
24 +€5.94

Non-Isolated Step-Down (Buck) Power Modules, PTH Series, Texas Instruments



AttributeValue
Maximum Output Current2.25A
Number of Outputs1
Maximum Switching Frequency300 Khz
Line Regulation±7 mV
Load Regulation±13 % VO
Mounting TypeThrough Hole
Package TypeDIP Module
Pin Count5
Dimensions15.24 x 12.7 x 7.93mm
Height7.93mm
Length15.24mm
Maximum Input Voltage4.5 V
Maximum Operating Temperature+85 °C
Width12.7mm
Minimum Operating Temperature-40 °C
Minimum Input Voltage18 V
