Name: RS PRO Circular Connector, 3 Contacts, Cable Mount, M12 Connector, Socket, Female, IP67
Brand: RS PRO
SKU: 124-6701
Price: 31.55 EUR
Availability: LimitedAvailability

M12 In-Line Push-Pull Cable Plug

From RS Pro, these push-pull plugs are serious contenders for your application. The convenient push-pull connection, makes it perfect in situations where accidental disconnects occur. That coupled with the IP67 rating, makes sure that this industrial connector excels in harsh environments. When choosing a female connector, this version should really be one you consider.

• Panel hole cutout diameter: 12 mm
• 2 way, 3 way, 4 way and 5 way all available
• Cable outer diameter: 4 mm to 6.5 mm see part numbers
124-6696 124-6697 124-6698 124-6699
• Cable outer diameter: 5 mm to 8 mm see part numbers
124-6700 124-6701 124-6703 124-6704
• Solder termination
• Chrome plated brass shell material
• Inline cable mounted

Features & Benefits

RS Pro Push-Pull

Select all	Attribute	Value
	Brand	RS PRO
	Number of Contacts	3
	Mounting Type	Cable Mount
	Connector Size	M12
	Plug/Socket	Socket
	Contact Gender	Female
	Termination Method	Solder
	IP Rating	IP67
	Current Rating	13.0A
	Body Orientation	Straight
	Voltage Rating	250.0 V
	Mating Type	Push-Pull
	Housing Material	Metal
	Pole Format	3P
	Contact Plating	Gold
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	+85°C
	Contact Material	Brass

	Select all
	Brand RS PRO
	Number of Contacts 3
	Mounting Type Cable Mount
	Connector Size M12
	Plug/Socket Socket
	Contact Gender Female
	Termination Method Solder
	IP Rating IP67
	Current Rating 13.0A
	Body Orientation Straight
	Voltage Rating 250.0 V
	Mating Type Push-Pull
	Housing Material Metal
	Pole Format 3P
	Contact Plating Gold
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature +85°C
	Contact Material Brass

RS PRO Circular Connector, 3 Contacts, Cable Mount, M12 Connector, Socket, Female, IP67

M12 In-Line Push-Pull Cable Plug
