Schneider Electric Acti 9 iC60N MCB Mini Circuit Breaker, 1 + N, 6 A, 6 kA, Curve C

Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): FR
Product Details

Acti9 iC60N MCBs 1+N Pole

iC60N curve B, C, D circuit breakers are multi-standard circuit breakers which combine circuit protection against short-circuit currents and circuit protection against overload currents

VisiSafe guarantees the downstream circuit is always safe regardless of overvoltage conditions, wear, or operator experience, even in the most demanding environments; The green strip indicates the safe position of contacts.
VisiTrip red window on the front face indicates fault tripping allowing fast diagnosis, resolution, and re-closing loads for easier building management and reduced downtime
Insulated terminals IP20
Large circuit labelling area
Double clip for dismounting with comb busbar in place

Merlin Gerin – MCBs

Miniature Circuit Breakers; Contact Position indicated by switch levers

Specifications
Attribute Value
Range Acti 9
Series iC60N
Number of Poles 1 + N
Current Rating 6 A
Tripping Characteristics Type C
Rated AC Voltage 12 → 60 V, 100 → 130 V, 220 → 240 V, 230 V
Breaking Capacity 6 kA
19 In stock for delivery within 2 working days
Unit of sale: Each
68.31
(exc. VAT)
84.02
(inc. VAT)
units
Per unit
1 - 9
€68.31
10 - 14
€64.84
15 +
€62.70
