MG Chemical 4225-1.35L Clear Epoxy Potting Compound

  • RS Stock No. 181-0362
  • Mfr. Part No. 4225-1.35L
  • Manufacturer MG Chemical
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CA
Product Details

4225 is a two-part epoxy conformal coating. It conforms to a durable, tough, semi-flexible coating with an excellent finish. It protects against harsh chemicals, humidity, corrosion, oil, dirt, thermal shock, and abrasion. It also prevents high-voltage arcing, short circuits, and static discharges. 4225 is a promising choice where extreme physical and chemical resistance are required.

2:1 mix ratio
Ready to spray
Inspection under UV light
Thin coating application - can be coated as thin as 0.5 mil
Excellent corrosion and chemical resistance

Specifications
Attribute Value
Product Material Epoxy
Package Type Can
Package Size 1.35 L
Cure Time 1 h @ 80 °C, 2 h @ +65 °C, 24 h @ +22 °C, 30 min @ +100 °C
Colour Clear
Maximum Operating Temperature +140°C
Minimum Operating Temperature -40°C
Viscosity Measurement 20cP/s
Specific Gravity 0.97
Operating Temperature Range -40 → +140 °C
Physical Form Liquid
Temporarily out of stock - back order for despatch when stock is available
Unit of sale: Each
Was €108.33
92.54
(exc. VAT)
113.82
(inc. VAT)
units
Per unit
1 - 14
€92.54
15 - 39
€88.87
40 +
€85.19
