Nichicon 100μF 25V dc Aluminium Electrolytic Capacitor, Through Hole 6.3 (Dia.) x 11mm +105°C 6.3mm 2.5mm

  • RS Stock No. 171-0679
  • Mfr. Part No. UPS1E101MED
  • Manufacturer Nichicon
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): JP
Product Details

Nichicon PS Series Capacitors

Nichicon PS Series Aluminium Electrolytic Capacitors are high reliability polymer capacitors which are rated up to 3000 hours. The PS series capacitors offer a high temperature range, high voltage, low impedance and high ripple current.

Features & Benefits:

High reliability
High ripple current
Long life up to 3000 hours
Lead free reflow soldering
Low ESR Wide temperature range
Miniature sized

Specifications
Attribute Value
Capacitance 100 µF
Voltage 25 V dc
Mounting Type Through Hole
Technology Electrolytic
Dimensions 6.3 (Dia.) x 11mm
Height 11mm
Minimum Operating Temperature -55°C
Diameter 6.3mm
Maximum Operating Temperature +105°C
Lifetime 2000h
Lead Pitch 2.5mm
Series PS
Leakage Current 4 μA
Tolerance ±20%
Ripple Current 250mA
800 In stock for delivery within 2 working days
Unit of sale: Each (In a Bag of 200)
0.089
(exc. VAT)
0.109
(inc. VAT)
units
Per unit
Per Bag*
200 - 200
€0.089
€17.80
400 - 400
€0.078
€15.60
600 - 800
€0.066
€13.20
1000 - 4800
€0.055
€11.00
5000 +
€0.044
€8.80
*price indicative
