Maxim Integrated ICL7135CQI+ PLCC Display Driver, 28 Segment, 28 Pin, 3 → 5.5 V
- RS Stock No.:
- 191-6999
- Mfr. Part No.:
- ICL7135CQI+
- Manufacturer:
- Maxim Integrated
View all Display Drivers
77 In stock for delivery within 2 working days
Price Each
€15.07
(exc. VAT)
€18.54
(inc. VAT)
| units | Per unit |
| 1 - 9 | €15.07 |
| 10 - 24 | €13.85 |
| 25 - 49 | €13.38 |
| 50 + | €13.15 |
Packaging Options:
- RS Stock No.:
- 191-6999
- Mfr. Part No.:
- ICL7135CQI+
- Manufacturer:
- Maxim Integrated
Technical data sheets
Legislation and Compliance
Product Details
Improved 2nd Source
±20,000 Count Resolution
Guaranteed ±1 Count accuracy
Over-range, under-range signals for auto-range capability
Easy interface to UARTs and μPs
TTL compatible, Multiplexed BCD outputs
True differential input. Zero reading guaranteed for 0 volt Input
True polarity at zero for precise null detection
Monolithic CMOS Design
Applications
Current
Material Thickness
Pressure
Resistance
Speed
Temperature
Voltage
Weight
±20,000 Count Resolution
Guaranteed ±1 Count accuracy
Over-range, under-range signals for auto-range capability
Easy interface to UARTs and μPs
TTL compatible, Multiplexed BCD outputs
True differential input. Zero reading guaranteed for 0 volt Input
True polarity at zero for precise null detection
Monolithic CMOS Design
Applications
Current
Material Thickness
Pressure
Resistance
Speed
Temperature
Voltage
Weight
Specifications
| Attribute | Value |
| Package Type | PLCC |
| Digital or Analogue Output | Digital |
| Number of Pins | 28 |
| Supply Voltage | 3 → 5.5 V |
| Number of Segments | 28 |
| Maximum Supply Current | 3mA |
| Minimum Operating Temperature | 0°C |
| Mounting Type | Through Hole |
| Maximum Operating Temperature | +70°C |
| Width | 16.66mm |
| Height | 3.96mm |
| Length | 19.2mm |
