Select all	Attribute	Value
	Brand	Texas Instruments
	Logic Function	Buffer
	Output Type	Open Drain
	Number of Elements per Chip	6
	Maximum Propagation Delay Time @ Maximum CL	10.6 ns @ 3.3 V, 15.2 ns @ 2.5 V, 7.5 ns @ 5 V
	Maximum High Level Output Current	-0.002mA
	Maximum Low Level Output Current	16mA
	Mounting Type	Surface Mount
	Package Type	SOIC
	Pin Count	14
	Logic Family	LV
	Dimensions	8.65 x 3.91 x 1.58mm
	Maximum Operating Supply Voltage	5.5 V
	Height	1.58mm
	Propagation Delay Test Condition	50pF
	Minimum Operating Supply Voltage	2 V
	Width	3.91mm
	Minimum Operating Temperature	-40 °C
	Maximum Operating Temperature	+85 °C
	Length	8.65mm

	Select all
	Brand Texas Instruments
	Logic Function Buffer
	Output Type Open Drain
	Number of Elements per Chip 6
	Maximum Propagation Delay Time @ Maximum CL 10.6 ns @ 3.3 V, 15.2 ns @ 2.5 V, 7.5 ns @ 5 V
	Maximum High Level Output Current -0.002mA
	Maximum Low Level Output Current 16mA
	Mounting Type Surface Mount
	Package Type SOIC
	Pin Count 14
	Logic Family LV
	Dimensions 8.65 x 3.91 x 1.58mm
	Maximum Operating Supply Voltage 5.5 V
	Height 1.58mm
	Propagation Delay Test Condition 50pF
	Minimum Operating Supply Voltage 2 V
	Width 3.91mm
	Minimum Operating Temperature -40 °C
	Maximum Operating Temperature +85 °C
	Length 8.65mm

Texas Instruments SN74LV07AD Hex Hex Inverter, 14-Pin SOIC

74LV Family, Texas Instruments
