Norgren Toggle Pneumatic Manual Control Valve X30 Series, G G 1/8, III B
- RS Stock No.:
- 724-267
- Mfr. Part No.:
- X3044302
- Manufacturer:
- Norgren
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
€114.60
(exc. VAT)
€140.96
(inc. VAT)
In Stock
- Plus 25 unit(s) shipping from 07 September 2026
- Plus 20 unit(s) shipping from 08 September 2026
- Plus 12 unit(s) shipping from 27 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | €114.60 |
| 5 - 9 | €111.16 |
| 10 + | €107.50 |
*price indicative
- RS Stock No.:
- 724-267
- Mfr. Part No.:
- X3044302
- Manufacturer:
- Norgren
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Norgren | |
| Control Mechanism | Toggle | |
| Product Type | Pneumatic Manual Control Valve | |
| Connection Thread Standard | G | |
| Port Type | Threaded, PIF | |
| Port Size | G 1/8 | |
| Series | X30 | |
| Control Button/Switch Colour | Black | |
| Maximum Operating Pressure | 10 bar | |
| Body Material | Zinc Alloy | |
| Maximum Flow Rate | 335L/min | |
| Valve Function | 5/2 | |
| Minimum Operating Temperature | 0°C | |
| Maximum Operating Temperature | 50°C | |
| Height | 24mm | |
| Width | 36mm | |
| Standards/Approvals | No | |
| Length | 115mm | |
| Number of Positions | 2 | |
| Number of Ports | 5 | |
| Thread Size | 1/8 in | |
| Model Number | III B | |
| Select all | ||
|---|---|---|
Brand Norgren | ||
Control Mechanism Toggle | ||
Product Type Pneumatic Manual Control Valve | ||
Connection Thread Standard G | ||
Port Type Threaded, PIF | ||
Port Size G 1/8 | ||
Series X30 | ||
Control Button/Switch Colour Black | ||
Maximum Operating Pressure 10 bar | ||
Body Material Zinc Alloy | ||
Maximum Flow Rate 335L/min | ||
Valve Function 5/2 | ||
Minimum Operating Temperature 0°C | ||
Maximum Operating Temperature 50°C | ||
Height 24mm | ||
Width 36mm | ||
Standards/Approvals No | ||
Length 115mm | ||
Number of Positions 2 | ||
Number of Ports 5 | ||
Thread Size 1/8 in | ||
Model Number III B | ||
RoHS Status: Exempt
IMI Norgren Pneumatic Manual Control Valve, 5/2 Function, 335L/min Maximum Flow Rate - X30 Series - X3044302
In need of a reliable way to control your pneumatic system? This IMI Norgren pneumatic manual control valve supports multi-directional flows and is able to receive air or push it into another valve. It has 5/2-way functionality (meaning it has five ports and two positions) so you can control it manually or mechanically for versatile operation. The valve has a working temperature range between 0°C and +70°C for use in extreme conditions. All five ports have standard G1/8 threaded ends that ensure secure connections, even in vibrating applications.
Features & Benefits
• Through-hole mounting method for secure installation
• Typical flow rate of 335L/min to support constant system use
• Zinc alloy body material to help prevent corrosion in demanding conditions
• Toggle lever-style switch for easy manual operation
• Nitrile rubber seals to stop compressed air escaping
Applications
• Marine engineering
• Farm machinery
• Industrial conveyors
• Crane hydraulics
• Food manufacturing
What pressure level can this pneumatic manual control valve withstand?
This pneumatic manual control valve has a maximum operating pressure of 10 bar or 145psi (pounds per square inch), so you can rely on it for high capacity.
