Omron Panel Mount Power Relay, 120V ac Coil, 25A Switching Current, DPST
- RS Stock No.:
- 329-991
- Mfr. Part No.:
- G7L-2A-T AC100/120
- Manufacturer:
- Omron
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 329-991
- Mfr. Part No.:
- G7L-2A-T AC100/120
- Manufacturer:
- Omron
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Omron | |
Coil Voltage | 120V ac | |
Contact Configuration | DPST | |
Mounting Type | Panel Mount | |
Switching Current | 25A | |
Number of Poles | 2 | |
Latching | No | |
Terminal Type | Quick Connect | |
Maximum Switching Voltage AC | 250V | |
Maximum Switching Current AC | 25 A | |
Length | 52.5mm | |
Coil Resistance | 5.26 kΩ | |
Contact Material | Ag Alloy | |
Maximum Operating Temperature | +60°C | |
Minimum Operating Temperature | -25°C | |
Standards Met | CSA, UL | |
Height | 53mm | |
Depth | 33.5mm | |
Series | G7L | |
Maximum Switching Power AC | 5.5 kVA | |
Dimensions | 52.5 x 33.5 x 53mm | |
Application | Power | |
Select all | ||
---|---|---|
Brand Omron | ||
Coil Voltage 120V ac | ||
Contact Configuration DPST | ||
Mounting Type Panel Mount | ||
Switching Current 25A | ||
Number of Poles 2 | ||
Latching No | ||
Terminal Type Quick Connect | ||
Maximum Switching Voltage AC 250V | ||
Maximum Switching Current AC 25 A | ||
Length 52.5mm | ||
Coil Resistance 5.26 kΩ | ||
Contact Material Ag Alloy | ||
Maximum Operating Temperature +60°C | ||
Minimum Operating Temperature -25°C | ||
Standards Met CSA, UL | ||
Height 53mm | ||
Depth 33.5mm | ||
Series G7L | ||
Maximum Switching Power AC 5.5 kVA | ||
Dimensions 52.5 x 33.5 x 53mm | ||
Application Power | ||
