Panasonic PCB Mount Latching Power Relay, 9V dc Coil, 16A Switching Current, SPST
- RS Stock No.:
- 134-7901
- Mfr. Part No.:
- ADW1209HTW
- Manufacturer:
- Panasonic
Subtotal (1 unit)*
€6.07
(exc. VAT)
€7.47
(inc. VAT)
- Final 2 unit(s), ready to ship from another location
Units | Per unit |
---|---|
1 + | €6.07 |
*price indicative
- RS Stock No.:
- 134-7901
- Mfr. Part No.:
- ADW1209HTW
- Manufacturer:
- Panasonic
Select all | Attribute | Value |
---|---|---|
Brand | Panasonic | |
Coil Voltage | 9V dc | |
Contact Configuration | SPST | |
Mounting Type | PCB Mount | |
Switching Current | 16A | |
Number of Poles | 1 | |
Latching | Yes | |
Terminal Type | PCB Pin | |
Maximum Switching Voltage AC | 277V | |
Length | 24mm | |
Coil Resistance | 202.5Ω | |
Coil Power | 400mW | |
Height | 18.8mm | |
Isolation Coil To Contact | 5kVrms | |
Life | Minimum of 1000000 (Mechanical) operations, Minimum of 20000 (Electrical) operations | |
Minimum Operating Temperature | -40°C | |
Depth | 10mm | |
Maximum Operating Temperature | +70°C | |
Contact Material | Silver Alloy | |
Standards Met | CSA, cUL, cULus, IEC 60335-1, PTI 325V, TV-8, UL, VDE | |
Maximum Switching Power AC | 4.432 kVA | |
Dimensions | 24 x 10 x 18.8mm | |
Application | Home Appliances, Industrial Equipment, Lighting Control Equipment, Security Equipment, Smart Meters, Various Power Supplies | |
Select all | ||
---|---|---|
Brand Panasonic | ||
Coil Voltage 9V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 16A | ||
Number of Poles 1 | ||
Latching Yes | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 277V | ||
Length 24mm | ||
Coil Resistance 202.5Ω | ||
Coil Power 400mW | ||
Height 18.8mm | ||
Isolation Coil To Contact 5kVrms | ||
Life Minimum of 1000000 (Mechanical) operations, Minimum of 20000 (Electrical) operations | ||
Minimum Operating Temperature -40°C | ||
Depth 10mm | ||
Maximum Operating Temperature +70°C | ||
Contact Material Silver Alloy | ||
Standards Met CSA, cUL, cULus, IEC 60335-1, PTI 325V, TV-8, UL, VDE | ||
Maximum Switching Power AC 4.432 kVA | ||
Dimensions 24 x 10 x 18.8mm | ||
Application Home Appliances, Industrial Equipment, Lighting Control Equipment, Security Equipment, Smart Meters, Various Power Supplies | ||
