Hongfa Europe GMBH PCB Mount Power Relay, 5V dc Coil, 10A Switching Current, SPST
- RS Stock No.:
- 176-2811
- Mfr. Part No.:
- HF118F/005-1HS5T(136)
- Manufacturer:
- Hongfa Europe GMBH
300 In stock for delivery within 2 working days
Price Each (In a Pack of 5)
€2.192
(exc. VAT)
€2.696
(inc. VAT)
Units | Per unit | Per Pack* |
|---|---|---|
| 5 + | €2.192 | €10.96 |
*price indicative
- RS Stock No.:
- 176-2811
- Mfr. Part No.:
- HF118F/005-1HS5T(136)
- Manufacturer:
- Hongfa Europe GMBH
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
10A switching capability
5kV dielectric strength (between coil and contacts)
Low height: 12.5 mm
Creepage distance >8mm
1 pole configurations available
Sockets available
Plastic sealed and flux proofed types available
Environmental friendly product
Outline Dimensions: (28.5 x 10.1 x 12.5) mm
5kV dielectric strength (between coil and contacts)
Low height: 12.5 mm
Creepage distance >8mm
1 pole configurations available
Sockets available
Plastic sealed and flux proofed types available
Environmental friendly product
Outline Dimensions: (28.5 x 10.1 x 12.5) mm
Specifications
Attribute | Value |
|---|---|
| Coil Voltage | 5V dc |
| Contact Configuration | SPST |
| Mounting Type | PCB Mount |
| Switching Current | 10A |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | PCB Pin |
| Maximum Switching Voltage AC | 440V |
| Maximum Switching Voltage DC | 125V dc |
| Maximum Switching Current AC | 10 A |
| Maximum Switching Current DC | 10 A |
| Length | 28.5mm |
| Coil Resistance | 113Ω |
| Coil Power | 220 → 290mW |
| Contact Material | Silver Alloy |
| Depth | 10.1mm |
| Life | 1 x 10^7 cycles |
| Isolation Coil To Contact | 10kV |
| Series | HF118F |
| Height | 12.5mm |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Maximum Switching Power AC | 2.5 kVA |
| Maximum Switching Power DC | 300 W |
