Finder PCB Mount Power Relay, 48V dc Coil, 6A Switching Current, SPDT
- RS Stock No.:
- 708-3172
- Mfr. Part No.:
- 34.51.7.048.0019
- Manufacturer:
- Finder
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 708-3172
- Mfr. Part No.:
- 34.51.7.048.0019
- Manufacturer:
- Finder
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Finder | |
Coil Voltage | 48V dc | |
Contact Configuration | SPDT | |
Mounting Type | PCB Mount | |
Switching Current | 6A | |
Number of Poles | 1 | |
Latching | No | |
Terminal Type | Through Hole | |
Maximum Switching Voltage AC | 400V ac | |
Length | 28mm | |
Coil Resistance | 12300Ω | |
Coil Power | 170mW | |
Series | 34 Series | |
Minimum Operating Temperature | -40°C | |
Maximum Operating Temperature | +85°C | |
Isolation Coil To Contact | 6kV | |
Depth | 5mm | |
Life | 10000000 (DC Mechanical) cycles, 60000 (Electrical) cycles | |
Height | 15mm | |
Contact Material | Silver Alloy | |
Maximum Switching Power AC | 1.5 kVA | |
Select all | ||
---|---|---|
Brand Finder | ||
Coil Voltage 48V dc | ||
Contact Configuration SPDT | ||
Mounting Type PCB Mount | ||
Switching Current 6A | ||
Number of Poles 1 | ||
Latching No | ||
Terminal Type Through Hole | ||
Maximum Switching Voltage AC 400V ac | ||
Length 28mm | ||
Coil Resistance 12300Ω | ||
Coil Power 170mW | ||
Series 34 Series | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +85°C | ||
Isolation Coil To Contact 6kV | ||
Depth 5mm | ||
Life 10000000 (DC Mechanical) cycles, 60000 (Electrical) cycles | ||
Height 15mm | ||
Contact Material Silver Alloy | ||
Maximum Switching Power AC 1.5 kVA | ||
