RS PRO PCB Mount Power Relay, 5V dc Coil, 25A Switching Current, SPST
- RS Stock No.:
- 800-4530P
- Manufacturer:
- RS PRO
Subtotal 1 unit (supplied in a box)*
€5.13
(exc. VAT)
€6.31
(inc. VAT)
In Stock
- 431 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | €5.13 |
*price indicative
- RS Stock No.:
- 800-4530P
- Manufacturer:
- RS PRO
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Coil Voltage | 5V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 25A | |
| Number of Poles | 1 | |
| Latching | No | |
| Terminal Type | Through Hole | |
| Maximum Switching Voltage AC | 250V ac | |
| Length | 30.5mm | |
| Coil Resistance | 27.8Ω | |
| Coil Power | 900mW | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | +85°C | |
| Depth | 16mm | |
| Isolation Coil To Contact | 4.5kV ac | |
| Height | 23.5mm | |
| Standards Met | CQC, CULus, RoHS Compliant | |
| Contact Material | Silver Alloy | |
| Life | 100000 (Electrical) Operations, 100000000 (Mechanical) Operations | |
| Maximum Switching Power AC | 6.25 kVA | |
| Application | Power | |
