ALWAYSE Ball Transfer Unit with 25mm diameter Steel ball

View all Ball Transfer Units
Bulk discount available

Subtotal (1 unit)*

€6.10

(exc. VAT)

€7.50

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 468 unit(s) ready to ship from another location
  • Plus 450 unit(s) shipping from 04 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4€6.10
5 - 9€5.86
10 - 24€5.70
25 +€5.58

*price indicative

RS Stock No.:
687-590
Mfr. Part No.:
100813
Manufacturer:
ALWAYSE
Find similar products by selecting one or more attributes.
Select all

Brand

ALWAYSE

Ball Diameter

25mm

Mounting Type

3-Hole Flange

Maximum Load

55kg

Load Ball Material

Steel

Case Material

Steel

Flange Diameter

73mm

RoHS Status: Exempt

COO (Country of Origin):
GB

ALWAYSE Bolt Fixing Ball Transfer Unit


The ALWAYSE 3-hole flange mount bolt fixing ball transfer unit is a highly efficient device with a maximum load capacity is 55kg. This unit is used to move or transfer loads in all direction with a maximum speed of 1m/s. It is available in a wide choice of load capacities, sizes and fixings.

Features and Benefits


Ball diameter is 25mm
Flange diameter is 73mm
Case material is steel
Flange type fitting
3%-5% of load force required to start motion
2% of load force required to maintain motion
Load ball material is steel with zinc plated
Self-cleaning hole in base of bearing cup
Operating temperature ranging between -30°C and 70°C

Certifications


ANSI/ESD S20.20:2014
BS EN 61340-5-1:2007
