Schneider Electric TeSys K LC1K Contactor, 24 V ac Coil, 3-Pole, 12 A, 5.5 kW, 3NO, 690 V ac

RS Stock No.:: 305-2026
Mfr. Part No.:: LC1K1210B7
Manufacturer:: Schneider Electric

Schneider Electric TeSys K LC1K Contactor, 24 V ac Coil, 3-Pole, 12 A, 5.5 kW, 3NO, 690 V ac

3 Within 1 working day(s) (IE stock)

23 Within 2 working day(s) (EU stock)

Price Each

€45.22

(exc. VAT)

€55.62

(inc. VAT)

Units	Per unit
1 - 9	€45.22
10 - 14	€42.92
15 +	€41.50

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:: 305-2026
Mfr. Part No.:: LC1K1210B7
Manufacturer:: Schneider Electric

Schneider Electric LC1K TeSys K Miniature Contactors

TeSys K Miniature Contactors from Schneider Electric combine long mechanical and electrical life to offer a high reliable contactor. The range has been designed for integration in control systems and for inductive motor applications. The TeSys K contactors offer quick simple setup while maintaining compliance with international standards. A special armature structure design allows all devices in the range, either AC or DC, to have the same physical size and panel footprint for convenience.

Features and Benefits

• Built-in auxiliary contacts for added switching capability
• Screw connections: IP20 finger-safe terminals with both North American and International terminal markings
• Can be panel mounted with screws or DIN Rail mounted
• Easily installed accessories
• Instantaneous auxiliary contact
• Flexible control circuit to suit a wide range of applications
• High-fault short circuit current ratings provide the flexibility to select any component

What does the utilisation category AC1 and AC3 mean for the TeSys contactors?

Contactor utilisation categories define the current making and breaking values, based on the type of load to be controlled and the operating cycle conditions.
AC-1: This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution.
AC-3: This applies to squirrel cage motors where breaking occurs while the motor is running.
Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units.

Are the TeSys K contactors suitable for applications in AC4 usage?

The LC1K series is suitable up to a maximum of 440 V ac in category AC4.

Is the TeSys K range a double break pole type contactor?

Yes the TeSys K range uses linear translation movement that provides double breaking of the poles.

Schneider Electric LC1K Series Contactor, 3NO, 12A Contact Current Rating - LC1K1210B7

This contactor by Schneider Electric is a crucial component in motor control applications. With a coil voltage of 24V AC, it offers reliable performance and efficient operation. Designed with a power rating of 5.5 kW, this contactor is suitable for a wide range of industrial settings.

Features & Benefits

• 12A contact current rating for optimal power distribution
• 690V AC contact voltage rating ensures safety and efficiency
• 3NO normal state configuration for versatile applications
• Screw terminal type for easy installation and maintenance
• Built-in bidirectional peak limiting diode suppressor for enhanced performance
• 1 NO auxiliary contact for additional functionality

Applications

• Ideal for motor control applications in industrial settings
• Suitable for AC-3 and AC-4 utilisation categories
• Used in power circuits with a maximum operating temperature of +50°C and a minimum operating temperature of -25°C

Can it handle a power rating of 5.5 kW?

Yes, this Schneider Electric contactor is designed to handle a power rating of 5.5 kW efficiently.

Will it work in applications with a coil voltage of 24V ac?

Yes, the contactor is specifically configured for use with a coil voltage of 24V ac.

Is it suitable for motor control applications?

Yes, this contactor is specifically designed for motor control applications, making it a reliable choice for industrial settings.

Attribute	Value
Coil Voltage	24 V ac
Number of Poles	3
Contact Voltage Rating	690 V ac
Contact Current Rating	12 A
Power Rating	5.5 kW
Range	TeSys K
Series	LC1K
Normal State Configuration	3NO
Number Of Auxiliary Contacts	1
Auxiliary Contact Configuration	1NO
Terminal Type	Screw
Length	58mm
Width	45mm
Depth	57mm
Better World Verification	Green Premium
Better World Product	Yes
Maximum Operating Temperature	+50°C
Mounting Style	Rail
Pole and Throw Configuration	3P
Minimum Operating Temperature	-25°C
