Lumberg 3 Pole Din Socket, DIN EN 60529, 5A, 250 V ac IP68, Female, Panel Mount
- RS Stock No.:
- 170-5529
- Mfr. Part No.:
- 0304 03
- Manufacturer:
- Lumberg
50 In stock for delivery within 2 working days
Added
Price Each (In a Box of 50)
€4.85
(exc. VAT)
€5.97
(inc. VAT)
| Units | Per unit | Per Box* |
| 50 + | €4.85 | €242.50 |
| *price indicative | ||
- RS Stock No.:
- 170-5529
- Mfr. Part No.:
- 0304 03
- Manufacturer:
- Lumberg
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
0304 Chassis Sockets
Front mounted with threaded joint and solder terminals
Standards
IEC60130-9
Lumberg DIN Connector
The Lumberg DIN connector is a 3-pole, female, din plug socket with an electrical rating of 250VAC and 5A. It is round with pins arranged in a circular pattern within the connector. It has chassis, cable mount plugs and sockets up to 12-way.
Features and Benefits
• Contact resistance ≤5mohm
• Front mount with threaded joint
• Long bend protection
• Operating temperature ranges between -40°C and 85°C
• Panel mount device
• Solder terminals
• Front mount with threaded joint
• Long bend protection
• Operating temperature ranges between -40°C and 85°C
• Panel mount device
• Solder terminals
Applications
• Automation technology
• Control engineering
• Medical instrumentation
• MIDI instruments
• PC keyboards
• Portable video devices and projectors
• Control engineering
• Medical instrumentation
• MIDI instruments
• PC keyboards
• Portable video devices and projectors
Certifications
• EN 60529
• IEC60130-9
• IP40 rated
• IP67 rated
• IP68 rated
• IEC60130-9
• IP40 rated
• IP67 rated
• IP68 rated
Lumberg Connectors Standard and SWUM™ - IP68
Lumberg Connectors Standard and SWUM™ - IP68 Chassis and cable mount plugs and sockets up to 12 way, with or without 360° shielding. Typical applications are control engineering, automation technology and medical instrumentation.
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 3 |
| Gender | Female |
| Mounting Type | Panel Mount |
| Termination Method | Solder |
| Body Orientation | Straight |
| Current Rating | 5A |
| Voltage Rating | 250 V ac |
| IP Rating | IP68 |
| DIN Number | DIN EN 60529 |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Contact Material | Brass |
| Contact Plating | Gold over Silver |
