Hongfa Europe GMBH PCB Mount Power Relay, 5V dc Coil, 10A Switching Current, SPST
- RS Stock No.:
- 176-2970
- Mfr. Part No.:
- HF14FF/005-1HTF
- Manufacturer:
- Hongfa Europe GMBH
Temporarily out of stock - back order for despatch 05-11-2024, delivery within 2 working days
Price Each (In a Pack of 2)
€2.45
(exc. VAT)
€3.01
(inc. VAT)
Units | Per unit | Per Pack* |
|---|---|---|
| 2 + | €2.45 | €4.90 |
*price indicative
- RS Stock No.:
- 176-2970
- Mfr. Part No.:
- HF14FF/005-1HTF
- Manufacturer:
- Hongfa Europe GMBH
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
10A switching capability
5kV dielectric strength (between coil and contacts)
Sockets available
Plastic sealed and dust protected types available
Environmental friendly product
Outline Dimensions: (29.0 x 13.0 x 26.0) mm
5kV dielectric strength (between coil and contacts)
Sockets available
Plastic sealed and dust protected types available
Environmental friendly product
Outline Dimensions: (29.0 x 13.0 x 26.0) mm
Specifications
Attribute | Value |
|---|---|
| Coil Voltage | 5V dc |
| Contact Configuration | SPST |
| Mounting Type | PCB Mount |
| Switching Current | 10A |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | PCB Pin |
| Maximum Switching Voltage AC | 277V |
| Maximum Switching Voltage DC | 30V dc |
| Maximum Switching Current DC | 10 A |
| Maximum Switching Current AC | 10 A |
| Length | 29mm |
| Coil Resistance | 47Ω |
| Coil Power | 530mW |
| Maximum Operating Temperature | +70°C |
| Isolation Coil To Contact | 5kV |
| Height | 26mm |
| Series | HF14FF |
| Minimum Operating Temperature | -40°C |
| Depth | 13mm |
| Contact Material | Silver Alloy |
| Life | 1 x 10^7 cycles |
| Maximum Switching Power DC | 300 W |
| Maximum Switching Power AC | 2.77 kVA |
