Lapp ÖLFLEX CLASSIC 115 CY Control Cable, 5 Cores, 2.5 mm², CY, Screened, 50m, Grey PVC Sheath, 13 AWG
- RS Stock No.:
- 444-0610
- Mfr. Part No.:
- 1136405
- Manufacturer:
- Lapp
Subtotal (1 reel of 50 metres)*
€404.53
(exc. VAT)
€497.57
(inc. VAT)
In Stock
- 6 unit(s) ready to ship from another location
- Plus 4 unit(s) shipping from 28 August 2025
- Plus 4 unit(s) shipping from 09 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | €404.53 | €8.091 |
*price indicative
- RS Stock No.:
- 444-0610
- Mfr. Part No.:
- 1136405
- Manufacturer:
- Lapp
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lapp | |
| Series | ÖLFLEX CLASSIC 115 CY | |
| Number of Cores | 5 | |
| Cross Sectional Area | 2.5 mm² | |
| American Wire Gauge | 13 AWG | |
| Conductor Material | Copper | |
| Sheath Material | PVC | |
| Sheath Colour | Grey | |
| Control Cable Type | CY | |
| Screened/Unscreened | Screened | |
| Screen Type | Tinned Copper Braid | |
| Length | 50m | |
| Outer Diameter | 11mm | |
| Minimum Bend Radius | Fixed - 6 x D Occasional Flexing - 20 x D | |
| Voltage Rating | 300/500 V | |
| Current Rating | 26 A | |
| Standards Met | CE | |
| CPR Certification | Eca | |
| Fire Behaviour | Flame Retardant | |
| Maximum Operating Temperature | +80°C | |
| Core Strands | 50/0.25 mm | |
| Insulation Material | PVC | |
| Oil Resistant | Yes | |
| Filler Material | Non-Wicking Filler | |
| Minimum Operating Temperature | -40°C | |
| Earth Cable | Yes | |
| Conductor Resistance | 13.7 Ω/km | |
Select all | ||
|---|---|---|
Brand Lapp | ||
Series ÖLFLEX CLASSIC 115 CY | ||
Number of Cores 5 | ||
Cross Sectional Area 2.5 mm² | ||
American Wire Gauge 13 AWG | ||
Conductor Material Copper | ||
Sheath Material PVC | ||
Sheath Colour Grey | ||
Control Cable Type CY | ||
Screened/Unscreened Screened | ||
Screen Type Tinned Copper Braid | ||
Length 50m | ||
Outer Diameter 11mm | ||
Minimum Bend Radius Fixed - 6 x D Occasional Flexing - 20 x D | ||
Voltage Rating 300/500 V | ||
Current Rating 26 A | ||
Standards Met CE | ||
CPR Certification Eca | ||
Fire Behaviour Flame Retardant | ||
Maximum Operating Temperature +80°C | ||
Core Strands 50/0.25 mm | ||
Insulation Material PVC | ||
Oil Resistant Yes | ||
Filler Material Non-Wicking Filler | ||
Minimum Operating Temperature -40°C | ||
Earth Cable Yes | ||
Conductor Resistance 13.7 Ω/km | ||
