Lapp ÖLFLEX CLASSIC 130 Control Cable, 3 Cores, 6 mm², YY, Unscreened, 50m, Grey LSZH Sheath, 9 AWG
- RS Stock No.:
- 819-9631
- Mfr. Part No.:
- 1123166
- Manufacturer:
- Lapp
Subtotal (1 reel of 50 metres)*
€458.32
(exc. VAT)
€563.73
(inc. VAT)
In Stock
- 1 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | €458.32 | €9.166 |
*price indicative
- RS Stock No.:
- 819-9631
- Mfr. Part No.:
- 1123166
- Manufacturer:
- Lapp
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lapp | |
| Series | ÖLFLEX CLASSIC 130 | |
| Number of Cores | 3 | |
| Cross Sectional Area | 6 mm² | |
| American Wire Gauge | 9 AWG | |
| Conductor Material | Bare Copper | |
| Sheath Material | LSZH | |
| Sheath Colour | Grey | |
| Control Cable Type | YY | |
| Screened/Unscreened | Unscreened | |
| Screen Type | Unscreened | |
| Minimum Bend Radius | 4 x Diameter | |
| Length | 50m | |
| Outer Diameter | 11.7mm | |
| Voltage Rating | 500 V | |
| CPR Certification | Dca | |
| Standards Met | CE, RoHS, UL | |
| Maximum Operating Temperature | +80°C | |
| Fire Behaviour | Flame Retardant, Low Smoke Zero Halogen (LSZH) | |
| Insulation Material | Zero Halogen | |
| Drain Wire | Yes | |
| Minimum Operating Temperature | -40°C | |
| Cable Shape | Multicore | |
Select all | ||
|---|---|---|
Brand Lapp | ||
Series ÖLFLEX CLASSIC 130 | ||
Number of Cores 3 | ||
Cross Sectional Area 6 mm² | ||
American Wire Gauge 9 AWG | ||
Conductor Material Bare Copper | ||
Sheath Material LSZH | ||
Sheath Colour Grey | ||
Control Cable Type YY | ||
Screened/Unscreened Unscreened | ||
Screen Type Unscreened | ||
Minimum Bend Radius 4 x Diameter | ||
Length 50m | ||
Outer Diameter 11.7mm | ||
Voltage Rating 500 V | ||
CPR Certification Dca | ||
Standards Met CE, RoHS, UL | ||
Maximum Operating Temperature +80°C | ||
Fire Behaviour Flame Retardant, Low Smoke Zero Halogen (LSZH) | ||
Insulation Material Zero Halogen | ||
Drain Wire Yes | ||
Minimum Operating Temperature -40°C | ||
Cable Shape Multicore | ||
