Brad from Molex 93601 Heavy Duty Power Connector Housing, Bottom Entry

RS Stock No.:: 253-3889
Mfr. Part No.:: 936010615
Manufacturer:: Brad from Molex

Brad from Molex 93601 Heavy Duty Power Connector Housing, Bottom Entry

1 / 1

Bulk discount available

Subtotal (1 bag of 30 units)**

€54.33

(exc. VAT)

€66.84

(inc. VAT)

Temporarily out of stock - back order for despatch 29-08-2025, delivery within 2 working days*

* Delivery dates may change based on your chosen quantity and delivery address.

Units	Per unit	Per Bag**
30 - 30	€1.811	€54.33
60 - 90	€1.731	€51.93
120 +	€1.675	€50.25

**price indicative

RS Stock No.:: 253-3889
Mfr. Part No.:: 936010615
Manufacturer:: Brad from Molex

Molex 93601 Series Heavy Duty Power Connector Housing, 3A size, Bulkhead Mounting Type - 936010615

This heavy duty power connector housing is designed for reliable performance in industrial applications. Classified as a single lever bulkhead housing, it features a robust polyamide construction that ensures durability. With an IP66 rating, this connector is well-suited for environments that require protection against dust and water ingress, making it a reliable choice for various tasks.

Features & Benefits

• Single lever design simplifies the locking mechanism
• Compatible with size 3A «21x21» inserts for flexible use
• Vertical mounting style facilitates easy installation
• Temperature range of -40°C to +120°C for extreme conditions
• Locking mechanism ensures secure connections during operation

Applications

• Utilised in automation systems for secure connections
• Suitable for electrical and mechanical assembly sectors
• Effective in environments requiring weatherproofing
• Ideal for use with size 3A connector inserts in various setups

What materials are used in the construction of this connector housing?

The housing is primarily made of polyamide, providing excellent durability and impact resistance, with a gasket crafted from NBR for improved sealing against environmental factors.

How does the IP66 rating benefit this connector in outdoor settings?

An IP66 rating indicates complete protection from dust and powerful water jets, making it suitable for machinery and installations exposed to harsh weather conditions.

What is the significance of the bottom entry design in this connector housing?

The bottom entry design allows for more efficient cable management and routing, simplifying installation and reducing potential stress on the cable connections.

Can this connector operate at high voltages?

Yes, it is rated for a maximum of 400V, making it suitable for various high-power applications across industrial environments.

What advantages does the single lever mechanism offer during installation?

The single lever mechanism enables quick and straightforward connections, ensuring that users can easily lock and unlock the connector without specialised tools or excessive force.

Find similar products by selecting one or more attributes.

	Select all
	Brand Brad from Molex
	Series 93601
	Type Single Lever Bulkhead Housing
	Mounting Type Bulkhead
	Size 3A
	Body Orientation Bottom Entry
	Contact Material Polyamide
