Alpha Wire 391850 Series White 0.75 mm² Hook Up Wire, 18 AWG, 16, 100 ft, Silicone Rubber, 391850 WH005
- RS Stock No.:
- 284-9467
- Mfr. Part No.:
- 391850 WH005
- Manufacturer:
- Alpha Wire
Subtotal (1 reel of 30 metres)*
€476.07
(exc. VAT)
€585.57
(inc. VAT)
Temporarily out of stock
- Shipping from 20 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | €476.07 | €15.869 |
*price indicative
- RS Stock No.:
- 284-9467
- Mfr. Part No.:
- 391850 WH005
- Manufacturer:
- Alpha Wire
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Cross Sectional Area | 0.75 mm² | |
| Product Type | Hook Up Wire | |
| Jacket Colour | White | |
| American Wire Gauge | 18AWG | |
| Core Strands | 16 | |
| Cable Length | 100ft | |
| Voltage | 20000 V | |
| Maximum Operating Temperature | 150°C | |
| Conductor Material | Tinned Copper | |
| Sub Type | Hookup Wire | |
| Minimum Operating Temperature | -40°C | |
| Standards/Approvals | RoHS | |
| Jacket Material | Silicone Rubber | |
| Cable Type | Stranded | |
| Fire Behaviour | Flame Retardant | |
| Series | 391850 | |
| Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Cross Sectional Area 0.75 mm² | ||
Product Type Hook Up Wire | ||
Jacket Colour White | ||
American Wire Gauge 18AWG | ||
Core Strands 16 | ||
Cable Length 100ft | ||
Voltage 20000 V | ||
Maximum Operating Temperature 150°C | ||
Conductor Material Tinned Copper | ||
Sub Type Hookup Wire | ||
Minimum Operating Temperature -40°C | ||
Standards/Approvals RoHS | ||
Jacket Material Silicone Rubber | ||
Cable Type Stranded | ||
Fire Behaviour Flame Retardant | ||
Series 391850 | ||
RoHS Status: Exempt
- COO (Country of Origin):
- US
The Alpha Wire hook-up wire is custom-tailored to specific applications, ranging from secure control cabinets to high-temperature ovens and off-road construction equipment. With a variety of insulations available, these wires are designed to withstand different temperature ranges, offer excellent wear and abrasion resistance, and meet diverse electrical performance requirements.
Resistance to oil, solvents and chemicals
RoHS compliant
