Alpha Wire Hook-up Wire TEFLON Series Grey 0.14 mm² Hook Up Wire, 26 AWG, 12601, 30.5m, PTFE Insulation, 2843/7 SL005
- RS Stock No.:
- 878-8363
- Mfr. Part No.:
- 2843/7 SL005
- Manufacturer:
- Alpha Wire
Subtotal (1 reel of 30 metres)*
€62.75
(exc. VAT)
€77.18
(inc. VAT)
- 12 unit(s) ready to ship from another location
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | €62.75 | €2.092 |
*price indicative
- RS Stock No.:
- 878-8363
- Mfr. Part No.:
- 2843/7 SL005
- Manufacturer:
- Alpha Wire
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Cross Sectional Area | 0.14 mm² | |
| Sheath Colour | Grey | |
| Cable Shape | Multicore | |
| American Wire Gauge | 26 AWG | |
| Core Strands | 12601 | |
| Length | 30.5m | |
| Insulation Material | PTFE | |
| Outer Diameter | 0.79mm | |
| Voltage Rating | 250 V | |
| Minimum Operating Temperature | -60°C | |
| Maximum Operating Temperature | 200°C | |
| Conductor Material | Copper | |
| Cable Type | High Temperature | |
| Wire Style | MIL-W-16878 | |
| Standards Met | California Proposition 65, EU Directive 2011/65/EU (RoHS2), MIL-DTL-16878/6 (Type ET), MIL-W-16878E-TYPE ET, NEMA HP3-ETXBAB, REACH Regulation (EC 1907/2006), RoHS Compliant, UL VW-1 | |
| Series | Hook-up Wire TEFLON | |
| Insulation Wall Thickness | 0.15mm | |
| Shield Type | Unshielded | |
| Number of Strands | 7 | |
| Resistant To | Chemicals, Oils, Solvents | |
| Size of Strands | 34 | |
Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Cross Sectional Area 0.14 mm² | ||
Sheath Colour Grey | ||
Cable Shape Multicore | ||
American Wire Gauge 26 AWG | ||
Core Strands 12601 | ||
Length 30.5m | ||
Insulation Material PTFE | ||
Outer Diameter 0.79mm | ||
Voltage Rating 250 V | ||
Minimum Operating Temperature -60°C | ||
Maximum Operating Temperature 200°C | ||
Conductor Material Copper | ||
Cable Type High Temperature | ||
Wire Style MIL-W-16878 | ||
Standards Met California Proposition 65, EU Directive 2011/65/EU (RoHS2), MIL-DTL-16878/6 (Type ET), MIL-W-16878E-TYPE ET, NEMA HP3-ETXBAB, REACH Regulation (EC 1907/2006), RoHS Compliant, UL VW-1 | ||
Series Hook-up Wire TEFLON | ||
Insulation Wall Thickness 0.15mm | ||
Shield Type Unshielded | ||
Number of Strands 7 | ||
Resistant To Chemicals, Oils, Solvents | ||
Size of Strands 34 | ||
