RS PRO Differential Manometer With 1 Pressure Port/s, Max Pressure Measurement 0.35 bar, RSCAL

RS Stock No.:: 205-0982
Manufacturer:: RS PRO

RS PRO Differential Manometer With 1 Pressure Port/s, Max Pressure Measurement 0.35 bar, RSCAL

Subtotal (1 unit)*

€664.84

(exc. VAT)

€817.75

(inc. VAT)

Temporarily out of stock

Shipping from 23 June 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	€664.84

*price indicative

RS Stock No.:: 205-0982
Manufacturer:: RS PRO

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Product Type	Manometer
	Accuracy	±0.4 %
	Number of Pressure Ports	1
	Maximum Pressure Measurement	0.35bar
	Minimum Pressure Measurement	-0.2bar
	Pressure Port Type	Differential
	Leak Testing	Yes
	Minimum/Maximum Recordings	Yes
	Data Logging	No
	Intrinsically Safe	Yes
	Power Source	Battery
	IP Rating	IP67, IP65
	Battery Type	AAA
	Minimum Operating Temperature	-25°C
	Maximum Overpressure	1bar
	Maximum Operating Temperature	50°C
	Display Type	LCD Backlight
	Battery Life	500h
	Standards/Approvals	CE
	Width	86mm
	Height	160mm
	Length	37mm
	Weight	250g
	Hazardous Area Certification	No
	Calibrated	RSCAL

	Select all
	Brand RS PRO
	Product Type Manometer
	Accuracy ±0.4 %
	Number of Pressure Ports 1
	Maximum Pressure Measurement 0.35bar
	Minimum Pressure Measurement -0.2bar
	Pressure Port Type Differential
	Leak Testing Yes
	Minimum/Maximum Recordings Yes
	Data Logging No
	Intrinsically Safe Yes
	Power Source Battery
	IP Rating IP67, IP65
	Battery Type AAA
	Minimum Operating Temperature -25°C
	Maximum Overpressure 1bar
	Maximum Operating Temperature 50°C
	Display Type LCD Backlight
	Battery Life 500h
	Standards/Approvals CE
	Width 86mm
	Height 160mm
	Length 37mm
	Weight 250g
	Hazardous Area Certification No
	Calibrated RSCAL

Manufacturer Information

COO (Country of Origin):: DE

RS PRO Differential Manometer

Introducing the RS PRO Differential Manometer. This high-quality device from RS PRO measures airflow and pressure with high accuracy and is a compact and rugged HVAC test and measurement instrument that offers a wide variety of measurement unit options, meaning that this is a functional and versatile tool that can be used across a wide range of pressure measurement applications, whilst offering reliable and accurate readings. This RS PRO manometer has been designed for with robust plug connections, silicone protective cover and a waterproof construction, while offering the most essential features that are necessary for routine maintenance and system troubleshooting applications in harsh industrial and field environments.

Features and Benefits:

This RS PRO manometer features 9 selectable units of measurement including bar, psi, mbar, Pa and mH2O for flexibility and additional versatility across a wide range of applications

This device offers a simultaneous display of pressure, ait velocity, airflow and temperature when required, without any delay and affecting the accuracy of the results at that point in time and improving testing efficiency

The manometer offers a large, high-resolution LCD screen for easy viewing of results and data measurement and long battery life, while the backlit screen allows it to be used in low light environments and ducting

It also has a leak testing function and allows max/min/avg. recording with a relative time stamp

Heavy duty and hard-wearing, this RS PRO manometer is waterproof and impact resistant with a IP65 / IP67 rating

The device is powered by 2 x AAA batteries with a low battery indicator and selectable ’auto power-off’ function to preserve battery life when not in use

Supplied with: Batteries, Protective Cover and Instruction Manual

Technical Features:

±0.1% FS ±1 Digit Accuracy

±350 mbar range

<1m second response time (typical)

Applications:

A manometer is a device that is used to measure pressure and the flow rate in the air, in gases or in liquids, depending on the application. These devices are generally compact and portable so that they can be taken to where the readings need to be measured and recorded. Manometers are versatile instruments that can be used across a wide range of industries and applications like:

HVAC systems maintenance

Meteorological and weather conditions monitoring

Gas pressure monitoring in piping systems

Fluid flow measurements

Physiological measurements such as blood pressure

Monitoring compressor systems operations

What is the difference between a manometer and a barometer?

Barometers or mercury manometers are devices that measure the atmospheric pressure around you. It is a very basic device that comes in a closed-end tube with a vacuum on the other end and measures as the pressure goes up or back down to the absolute pressure point. Manometers also measure atmospheric pressure this, however, in addition to this, manometers have additional features that can measure absolute pressure, differential pressure and gauge pressure and can be used in a wide range of servicing and maintenance applications to ensure that all parts that work using pressure are maintained and fully functional to ensure that downtime is limited.

What are the measurement units that this manometer can read?

This manometer measures in 9 different units: mbar, bar, Pa, kPa, MPa, mmHg, inHg, PSI and mH2O
