Preci-Dip 410 Series Straight PCB PCB Socket, 20-Contact, 2 Row, 2.54 mm Pitch Solder

View all PCB Sockets

Subtotal (1 pack of 5 units)*

€12.24

(exc. VAT)

€15.055

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 10 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
5 +€2.448€12.24

*price indicative

Packaging Options:
RS Stock No.:
702-3038
Mfr. Part No.:
410-87-220-01-640101
Manufacturer:
Preci-Dip
Find similar products by selecting one or more attributes.
Select all

Brand

Preci-Dip

Number of Contacts

20

Product Type

PCB Socket

Sub Type

Board-to-Board

Number of Rows

2

Pitch

2.54mm

Current

12A

Housing Material

Black Glass Filled Polyester

Termination Type

Solder

Mount Type

PCB

Orientation

Straight

Connector System

Board-to-Board

Voltage

150 V

Series

410

Row Pitch

2.54mm

Minimum Operating Temperature

-55°C

Maximum Operating Temperature

125°C

Contact Plating

Gold Flash

Contact Gender

Female

Contact Material

Beryllium Copper Alloy

Standards/Approvals

No

COO (Country of Origin):
CH

2.54 mm IC Sockets Ø 0.47 mm pin


These Swiss Preci-dip solder tail through hole Socket Connectors are for mating pin diameters of 0.47 mm.

Sockets have Tin plated Brass sleeves with Flash Gold plated Beryllium Copper (4 finger) contact clips

Through Hole connectors are Standoff type with a Pin length of 3.2 mm

The SMD mounting connectors are Gull-Wing type

Standards

UL 94V-0
