Select all	Attribute	Value
	Brand	RS PRO
	Cross Sectional Area	2.5 mm²
	Number of Cores	3
	Sheath Colour	White
	Length	100m
	Cable Type	Fire Performance
	Outer Diameter	9.2 → 11.4mm
	CPR Certification	Eca
	Voltage Rating	500 V
	European Harmonised Code	H05Z1Z1-F
	Minimum Operating Temperature	-5°C
	Standards Met	BS EN 50525
	Fire Behaviour	Flame Retardant
	Conductor Resistance	7.98 Ω/km
	Insulation Material	Thermoplastic
	American Wire Gauge	13 AWG
	Number of Strands	45
	Maximum Operating Temperature	+70°C
	Conductor Material	Copper
	Size of Strands	0.25 mm

	Select all
	Brand RS PRO
	Cross Sectional Area 2.5 mm²
	Number of Cores 3
	Sheath Colour White
	Length 100m
	Cable Type Fire Performance
	Outer Diameter 9.2 → 11.4mm
	CPR Certification Eca
	Voltage Rating 500 V
	European Harmonised Code H05Z1Z1-F
	Minimum Operating Temperature -5°C
	Standards Met BS EN 50525
	Fire Behaviour Flame Retardant
	Conductor Resistance 7.98 Ω/km
	Insulation Material Thermoplastic
	American Wire Gauge 13 AWG
	Number of Strands 45
	Maximum Operating Temperature +70°C
	Conductor Material Copper
	Size of Strands 0.25 mm

RS PRO, Fire Performance, 100m 3 Core, White Power Cable +70°C

RS PRO 3-Core 2.5 mm² H05Z1Z1-F Power Cable, White, 100 m, 500 V

Features and Benefits
