Omron PCB Mount Power Relay, 24V dc Coil, 20A Switching Current, DPST
- RS Stock No.:
- 684-0201
- Mfr. Part No.:
- G7L-2A-P 24DC
- Manufacturer:
- Omron
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 684-0201
- Mfr. Part No.:
- G7L-2A-P 24DC
- Manufacturer:
- Omron
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Omron | |
Coil Voltage | 24V dc | |
Contact Configuration | DPST | |
Mounting Type | PCB Mount | |
Switching Current | 20A | |
Number of Poles | 2 | |
Latching | No | |
Terminal Type | Through Hole | |
Maximum Switching Voltage AC | 250V ac | |
Length | 52.5mm | |
Coil Resistance | 303Ω | |
Coil Power | 1.9W | |
Isolation Coil To Contact | 4kV ac | |
Depth | 35.5mm | |
Minimum Operating Temperature | -25°C | |
Maximum Operating Temperature | +60°C | |
Height | 47mm | |
Series | G7L | |
Life | 1000000 (Electrical) cycles, 1000000 (Mechanical) cycles | |
Maximum Switching Power AC | 4.4 kVA | |
Application | Power | |
Select all | ||
---|---|---|
Brand Omron | ||
Coil Voltage 24V dc | ||
Contact Configuration DPST | ||
Mounting Type PCB Mount | ||
Switching Current 20A | ||
Number of Poles 2 | ||
Latching No | ||
Terminal Type Through Hole | ||
Maximum Switching Voltage AC 250V ac | ||
Length 52.5mm | ||
Coil Resistance 303Ω | ||
Coil Power 1.9W | ||
Isolation Coil To Contact 4kV ac | ||
Depth 35.5mm | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature +60°C | ||
Height 47mm | ||
Series G7L | ||
Life 1000000 (Electrical) cycles, 1000000 (Mechanical) cycles | ||
Maximum Switching Power AC 4.4 kVA | ||
Application Power | ||
