Sensata / Crydom H12 Series Solid State Relay, 90 A Load, Panel Mount, 530 Vrms Load, 32V dc Control
- RS Stock No.:
- 145-0596
- Mfr. Part No.:
- H12D4890K
- Manufacturer:
- Sensata / Crydom
Bulk discount available
Subtotal (1 unit)*
€117.32
(exc. VAT)
€144.30
(inc. VAT)
Temporarily out of stock
- Shipping from 31 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | €117.32 |
| 5 - 9 | €111.47 |
| 10 - 24 | €105.59 |
| 25 - 49 | €99.73 |
| 50 + | €93.86 |
*price indicative
- RS Stock No.:
- 145-0596
- Mfr. Part No.:
- H12D4890K
- Manufacturer:
- Sensata / Crydom
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Sensata / Crydom | |
| Maximum Load Current | 90A | |
| Product Type | Solid State Relay | |
| Mount Type | Panel | |
| Maximum Load Voltage | 530Vrms | |
| Minimum Load Voltage | 48Vrms | |
| Maximum Control Voltage | 32V dc | |
| Minimum Control Voltage | 4V dc | |
| Series | H12 | |
| Terminal Type | Screw | |
| Minimum Operating Temperature | -40°C | |
| Switching Function | Zero Cross Switching | |
| Maximum Operating Temperature | 80°C | |
| Height | 26.4mm | |
| Length | 44.5mm | |
| Standards/Approvals | No | |
| Output Type | SCR | |
| Capacitance | 8pF | |
| Off State Leakage Current | 10mArms | |
| Select all | ||
|---|---|---|
Brand Sensata / Crydom | ||
Maximum Load Current 90A | ||
Product Type Solid State Relay | ||
Mount Type Panel | ||
Maximum Load Voltage 530Vrms | ||
Minimum Load Voltage 48Vrms | ||
Maximum Control Voltage 32V dc | ||
Minimum Control Voltage 4V dc | ||
Series H12 | ||
Terminal Type Screw | ||
Minimum Operating Temperature -40°C | ||
Switching Function Zero Cross Switching | ||
Maximum Operating Temperature 80°C | ||
Height 26.4mm | ||
Length 44.5mm | ||
Standards/Approvals No | ||
Output Type SCR | ||
Capacitance 8pF | ||
Off State Leakage Current 10mArms | ||
Crydom H1 Series Panel Mount Solid State Relays
Crydom H1 series robust and versatile panel mount solid state relays. These powerful SSRs have superior thermal performance thanks to the use of DBC technology. The H1 series solid state relays feature anti-rotation barriers, SCR output, flexible control voltage options and a wide range of power ratings.
Features and Benefits
Snubber Included;SCR output for heavy industrial loads;Zero Voltage or instantaneous turn-on outputs;UL/CSA/VDE Approved, CE Compliant to EN60950-1;Anti-rotation barriers;DC control;Direct Bond Copper substrate;EMC Compliant to Level 3;Direct Power Lead Frame;Epoxy Free Design
