Allen Bradley 100S-C Contactor, 24V ac Coil, 3-Pole, 9 A, 13 kW 24V ac, 3 NO, 690V ac
- RS Stock No.:
- 269-3082
- Mfr. Part No.:
- 100S-C09KJ23BC
- Manufacturer:
- Allen Bradley
Subtotal (1 unit)*
€93.78
(exc. VAT)
€115.35
(inc. VAT)
In Stock
- Plus 3 unit(s) shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | €93.78 |
*price indicative
- RS Stock No.:
- 269-3082
- Mfr. Part No.:
- 100S-C09KJ23BC
- Manufacturer:
- Allen Bradley
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Allen Bradley | |
| Coil Voltage | 24V ac | |
| Product Type | Contactor | |
| Number of Poles | 3 | |
| Contact Voltage | 690V ac | |
| Contact Current | 9A | |
| Series | 100S-C | |
| Power Rating | 13kW | |
| Mount Type | DIN Rail | |
| Normal State Configuration | 3 NO | |
| Auxiliary Contact Configuration | 2 NO/3 NC | |
| Terminal Type | Screw | |
| Minimum Operating Temperature | -25°C | |
| Control Circuit Voltage Uc | 24V ac | |
| Maximum Operating Temperature | 60°C | |
| Width | 140mm | |
| Depth | 899mm | |
| Length | 899mm | |
| Standards/Approvals | SUVA LVD Type Approval, IECEE Scheme | |
| Select all | ||
|---|---|---|
Brand Allen Bradley | ||
Coil Voltage 24V ac | ||
Product Type Contactor | ||
Number of Poles 3 | ||
Contact Voltage 690V ac | ||
Contact Current 9A | ||
Series 100S-C | ||
Power Rating 13kW | ||
Mount Type DIN Rail | ||
Normal State Configuration 3 NO | ||
Auxiliary Contact Configuration 2 NO/3 NC | ||
Terminal Type Screw | ||
Minimum Operating Temperature -25°C | ||
Control Circuit Voltage Uc 24V ac | ||
Maximum Operating Temperature 60°C | ||
Width 140mm | ||
Depth 899mm | ||
Length 899mm | ||
Standards/Approvals SUVA LVD Type Approval, IECEE Scheme | ||
RoHS Status: Exempt
The Rockwell Automation 100S series safety contactors provide mechanically linked positively guided contacts, which is required in feedback circuits for modern safety applications. The mechanically linked N.C auxiliary contacts do not change state when a power pole welds. In addition, these auxiliary contacts are ideally suited for low energy applications or feedback control circuits with multiple series connected N.C auxiliary contacts.
Front mounted auxiliary contacts
SUVA third party certification
Protective cover to prevent manual operation
Red contact housing for easy identification
Gold bifurcated auxiliary contacts
