Texas Instruments, Transmitter IC 4 LVCMOS, LVTTL LVDS, 56-Pin TSSOP

View all LVDS Interface Ics
Bulk discount available

Subtotal (1 tube of 34 units)*

€195.534

(exc. VAT)

€240.516

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 22 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Tube*
34 - 34€5.751€195.53
68 - 136€5.464€185.78
170 +€4.917€167.18

*price indicative

RS Stock No.:
121-8723
Mfr. Part No.:
DS90CR285MTD/NOPB
Manufacturer:
Texas Instruments
Find similar products by selecting one or more attributes.
Select all

Brand

Texas Instruments

Number of Drivers

4

Product Type

Transmitter IC

Input Type

LVCMOS, LVTTL

Number of Receivers

28

Sub Type

Transmitter

Output Type

LVDS

Transmission Data Rate

1848Mbps

Number of Elements per Chip

4

Mount Type

Surface

Package Type

TSSOP

Pin Count

56

Minimum Supply Voltage

3V

Differential Input High Threshold Voltage

0.1V

Maximum Supply Voltage

3.6V

Differential Input Low Threshold Voltage

-0.1V

ESD Protection

Yes

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

85°C

Height

0.9mm

Width

6.1 mm

Standards/Approvals

RoHS

Series

DS90CR285

Length

14mm

Automotive Standard

No

COO (Country of Origin):
TW

Channel Link Serialiser/Deserialiser, Texas Instruments


LVDS Communication


Low Voltage Differential Signaling, or LVDS, is an electrical signaling system that can run at very high speeds over cheap, twisted-pair copper cables.

Applications: Firewire, SATA, SCSI
