Wurth Elektronik WR-PHD Series Right Angle Through Hole Pin Header, 8 Contact(s), 2.54 mm Pitch, 2 Row, Unshrouded

View all PCB Headers
Bulk discount available

Subtotal (1 reel of 350 units)*

€449.40

(exc. VAT)

€552.65

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 30 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Reel*
350 - 350€1.284€449.40
700 - 1400€1.193€417.55
1750 +€1.113€389.55

*price indicative

RS Stock No.:
176-9896
Mfr. Part No.:
610108249121
Manufacturer:
Wurth Elektronik
Find similar products by selecting one or more attributes.
Select all

Brand

Wurth Elektronik

Product Type

Pin Header

Series

WR-PHD

Current

3A

Pitch

2.54mm

Housing Material

Polyamide

Number of Contacts

8

Number of Rows

2

Orientation

Right Angle

Shrouded/Unshrouded

Unshrouded

Connector System

Wire-to-Board

Mount Type

Through Hole

Contact Material

Copper Alloy

Contact Plating

Gold

Minimum Operating Temperature

-40°C

Row Pitch

2.54mm

Termination Type

Solder

Maximum Operating Temperature

105°C

Tail Pin Length

7.62mm

Contact Gender

Male

Standards/Approvals

No

Mating Pin Length

6mm

Voltage

250 V

COO (Country of Origin):
TW
The Wurth Elektronik WR-PHD is a 8 pin, 2.54 mm, double (dual) row, right angled, SMT mount pin header with gold contact plating. It has 600V AC withstanding voltage and 20mΩ contact resistance.

RoHS compliant

Operating temperature ranges between -40 up to +105 °C

25 mating cycles
