Alpha Wire Green 0.75 mm² Hook Up Wire, 18 AWG, 16/0.25 mm, 30m, PVC Insulation, 3055 GR005
- RS Stock No.:
- 331-761
- Distrelec Article No.:
- 300-83-074
- Mfr. Part No.:
- 3055 GR005
- Manufacturer:
- Alpha Wire
Subtotal (1 reel of 30 metres)*
€26.88
(exc. VAT)
€33.06
(inc. VAT)
In Stock
- 15 unit(s) ready to ship from another location
- Plus 12 unit(s) shipping from 22 September 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
---|---|---|
1 + | €26.88 | €0.896 |
*price indicative
- RS Stock No.:
- 331-761
- Distrelec Article No.:
- 300-83-074
- Mfr. Part No.:
- 3055 GR005
- Manufacturer:
- Alpha Wire
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Alpha Wire | |
Cross Sectional Area | 0.75 mm² | |
Sheath Colour | Green | |
American Wire Gauge | 18 AWG | |
Cable Shape | Single Core | |
Core Strands | 16/0.25 mm | |
Length | 30m | |
Insulation Material | PVC | |
Outer Diameter | 2.01mm | |
Voltage Rating | 300 V | |
Maximum Operating Temperature | +105°C | |
Minimum Operating Temperature | -40°C | |
Conductor Material | Copper | |
Wire Style | UL1007 | |
Standards Met | UL Listed | |
Fire Behaviour | Flame Retardant | |
Insulation Wall Thickness | 0.4mm | |
Size of Strands | 0.25 mm | |
Number of Strands | 16 | |
Select all | ||
---|---|---|
Brand Alpha Wire | ||
Cross Sectional Area 0.75 mm² | ||
Sheath Colour Green | ||
American Wire Gauge 18 AWG | ||
Cable Shape Single Core | ||
Core Strands 16/0.25 mm | ||
Length 30m | ||
Insulation Material PVC | ||
Outer Diameter 2.01mm | ||
Voltage Rating 300 V | ||
Maximum Operating Temperature +105°C | ||
Minimum Operating Temperature -40°C | ||
Conductor Material Copper | ||
Wire Style UL1007 | ||
Standards Met UL Listed | ||
Fire Behaviour Flame Retardant | ||
Insulation Wall Thickness 0.4mm | ||
Size of Strands 0.25 mm | ||
Number of Strands 16 | ||
