onsemi FSB50550BS, AC Induction, DC Motor Motor Driver IC, 500 V 1 A 23-Pin, SPM5Q
- RS Stock No.:
- 135-8693
- Mfr. Part No.:
- FSB50550BS
- Manufacturer:
- onsemi
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 135-8693
- Mfr. Part No.:
- FSB50550BS
- Manufacturer:
- onsemi
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | onsemi | |
| Product Type | Motor Driver IC | |
| Motor Type | AC Induction, DC Motor | |
| Configuration | Array 6 | |
| Maximum IGBT Collector Current | 1A | |
| Maximum Collector Emitter Voltage Vceo | 500V | |
| Mount Type | Surface | |
| Package Type | SPM5Q | |
| Pin Count | 23 | |
| Maximum Supply Voltage | 400V | |
| Minimum Supply Voltage | 300V | |
| Minimum Operating Temperature | -40°C | |
| Typical Switching Frequency | 10kHz | |
| Maximum Operating Temperature | 150°C | |
| Height | 3.15mm | |
| Series | Motion SPM 5 | |
| Standards/Approvals | No | |
| Width | 12 mm | |
| Length | 29mm | |
| Inverter Power Rating | 200W | |
| Supply Current | 800μA | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand onsemi | ||
Product Type Motor Driver IC | ||
Motor Type AC Induction, DC Motor | ||
Configuration Array 6 | ||
Maximum IGBT Collector Current 1A | ||
Maximum Collector Emitter Voltage Vceo 500V | ||
Mount Type Surface | ||
Package Type SPM5Q | ||
Pin Count 23 | ||
Maximum Supply Voltage 400V | ||
Minimum Supply Voltage 300V | ||
Minimum Operating Temperature -40°C | ||
Typical Switching Frequency 10kHz | ||
Maximum Operating Temperature 150°C | ||
Height 3.15mm | ||
Series Motion SPM 5 | ||
Standards/Approvals No | ||
Width 12 mm | ||
Length 29mm | ||
Inverter Power Rating 200W | ||
Supply Current 800μA | ||
Automotive Standard No | ||
Motion SPM® 5 Series Motor Drivers, Fairchild Semiconductor
A range of Advanced Smart Power Modules from Fairchild Semiconductor which provide Compact high performance solutions for many inverter motor drive applications. The modules integrate optimized gate drive for the built-in power MOSFETs to minimize EMI and losses and also include multiple on-module protection features including under-voltage lockouts and thermal monitoring. The modules are suitable for driving AC Induction, BLDC (Brushless DC) and PMSM (Permanent Magnet Synchronous) motors.
